Page 10 For technical questions, please call 1-888-866-5797. Item 56407
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Bit Chuck 1
2 Front Cover 1
3 Lock Ring 2
4 Spring Column Pin 2
5 Locking Lever 1
6 Hex Socket Bolt M14×70 4
7 ø14 Spring Washer 4
8 ø14 Flat Washer 4
9 O Ring ø77×ø2.9 1
10 Fluorin O Ring ø39×ø5 2
11 Impact Hammer 1
12 Hammer Ring 1
13 Shock Absorption Ferrule 1
14 Locking Ring 1
15 M14 6 Nut 4
16 Aluminum Housing 1
17 Hex Socket Bolt M10×70 4
18 ø10 Spring Washer 4
19 ø10 Flat Washer 4
20 O Ring ø53.8xø6 2
21 Impact Piston 1
22 Cylinder 1
23 Piston Pin ø14×61.5 1
24 Piston 1
25 Connecting Rod Assembly 1
26 Needle Bearing 1
27 Square Seal Ring ø97x3.5x3.2 1
28 Cylinder Seat 1
29 O Ring ø87×ø3.5 2
30 Cover 1
31 Housing 1
32 Ball Bearing 6205 1
33 Final Gear 1
34 Palt Key 4×18 2
35 ø24 Retaining Ring 1
36 Paper Washer 1
37 Ball Bearing 6004 LUV CW 1
38 ø42 Retaining Ring 1
39 Double Teeth Pin ø16×50 1
40 Needle Bearing Hk1612 2
41 Double Teeth 1
42 Gear Cover 1
43 Hex Socket Bolt M8×20 5
44 Hex Socket Bolt M8×25 6
45 Stop Block 1
46 ø5 Flat Washer 1
47 Hex Socket Bolt M5×12 1
48 Ball Bearing 6206 LUV CW 1
49 Crank Shaft 1
50 Oil Tank Cover 1
51 Deflating Valve 1
Part Description Qty
52 Wool Block 1
53 Bottom Cover 1
54 Stator Assembly 1
55 Stator 110-120V 1
56 Positioning Bracket 1
57 Armature 110-120V 1
58 Tapping Screw ST4.8×70 2
59 Carbon Brush 2
60 Coil Spring 2
61 Carbon Brush Bracket 1
62 Machine Screw M4×8 2
63 Fan 1
64 Bearing Cover 1
65 Ball Bearing 6301ZV CW 1
66 Hex Socket Bolt M6×20 1
67 M12×1 Lock Nut 1
68 ø37 Retaining Ring 1
69 Cover 1
70 Fan Cover 1
71 Hex Socket Bolt M6×15 4
72 Mandrel Subassembly 1
73 Shock Absorption Spring 1
74 Support 2
75 Side Handle Support 1
76 Tapping Screw ST4.2×16 5
77 Side Handle Cover 1
78 Side Handle Assembly 1
79 M10 Lock Nut 2
80 ø6 Flat Washer 8
81 Hex Socket Bolt M6×35 4
82 Main Handle Support 1
83 Side Handle Assembly Base 1
86 Switch Cover 1
87 Trigger 1
88 Main Handle 1
89 Hex Socket Bolt M6×50 4
90 Tapping Screw ST4.2×18 4
91 Main Handle Cover 1
92 Switch 1
93 Power Cord Clip 1
94 Power Cord Armor 1
95 Power Cord 1
96 Wire Cover 1
97 Screw Sleeve 8
98 ø10 Flat Washer 2
99 ø6×ø10.5 Flat Washer 4
801 Front Cover Subassembly 1
803 Cylinder Subassembly 1
802 Piston 1
804 Housing Subassembly 1
