Hercules HE32 User Manual

Page 10 )RUWHFKQLFDOTXHVWLRQVSOHDVHFDOO Item 57150
PARTS LIST AND DIAGRAM
Parts List
3DUW 'HVFULSWLRQ 4W\
1 Chisel Chuck 1
2 6SULQJ&ROXPQ3LQĭ[ 2
3 Locking Lever 1
4 Clamp ring 2
5 Front Cover Assembly 1
6 Hex .Socket Bolt M8x55(12.9) 4
7 25LQJĭ[ĭ 1
8 Impact Hammer 1
9 )OXRULQ25LQJĭ[ĭ 2
10 Limit ring 1
11 Shock absorption ring 1
13 Aluminum Head 1
14 M8x9 Nut 4
15 Hex .Socket Bolt M10x55 4
16 Cylinder seat 1
17 Shock Absorption Ferrule 1
18 Cylinder 1
19 Impact Piston 1
20 Piston ring 2
21 Gas Press Piston 1
22 3LVWRQ3LQĭ[ 1
23 25LQJɎ[Ɏ 1
24 Connecting Rod Asm. 1
25 25LQJĭ[ĭ 2
26 Hex Socket Bolt M6x20 10
27 Cover 1
28 Seal Ring 1
29 Final Gear 1
30 Ball Bearing 6203 RS 2
31 Housing Assembly 1
32 Ball Bearing 6205 RS 1
33 Crank Shaft 1
34 Ɏ)ODW:DVKHUĭ[ĭ[ 1
35 Hex Socket Bolt M8x30x12.9 3
36 Oil Tank Cover 1
37 Hex .Socket Bolt M4x12 4
38 Wool block 1
39 Cover plate 1
40 Double teeth 1
41 HK1612 Needle Bearing 2
42 ĭ5HWDLQLQJ5LQJ 1
3DUW 'HVFULSWLRQ 4W\
43 Armature 110-120V 1
44 ST4.8x65 Tapping Screw 2
46 Stator 110-120V 1
47 Stator Asm. 1
48 Helical spring 2
49 Carbon brush wire 2
50 Carbon Brush 2
51 ST4.2x10 Tapping Screw 2
52 Hex .Socket Bolt M6x25 2
53 Fan Cover 1
54 Rivet 2
55 Cord Clip 1
56 Blind flange 1
57 ST4.2x16 Tapping Screw 4
58 Cord Armor 1
59 Cord 1
60 Switch seat 1
61 Switch 110-120V 1
62 ST4.8x35 Tapping Screw 4
63 Guide plate 2
64 Handle seat 1
65 Hex Socket Bolt M6x15 6
66 Shock Absorption Spring 2
67 Main Handle 1
68 Scutcheon 2
69 3LQĭ[ 2
70 Hex Socket Bolt M8x140 1
71 Disk with gap 2
72 Clamping 2
73 Side Handle Asm. Steel Tie 1
74 Side Handle 1
75 Function Knob 1
76 M8x6.4 Nut 1
77 Function Knob cover 1
78 Oil Bottle 1
80 )ODW:DVKHUɎ[Ɏ[ 5
81 Needle Bearing HK162216 1
82 6000 Z Ball Bearing 1
84 Fan 1
85 M5x15 Embedding Screw 1
