Page 10 )RUWHFKQLFDOTXHVWLRQVSOHDVHFDOO Item 56844
PARTS LIST AND DIAGRAM
Parts List
3DUW 'HVFULSWLRQ 4W\
1 Hammer Rod Protector 1
2 Chuck Ring 1
3 Retaining Ring Ø26 1
4 Support Washer 1
5 Rubber Ring 1
6 Lock Bead Sheath 1
7 Insert Block 2
8 Spring Rack 1
9 Flex Sheath Spring 1
10 Retaining Ring Ø28 1
11 Direction Selector 1
12 Hex Socket Bolt M4×16 2
13 Front Shade 1
14 Cover 1
15 O Ring Ø13.94×Ø2.62 1
16 Dial Staff Sheath 1
17 Spring 1
18 Mode Knob Spring 1
19 Mode Knob 1
20 Screw ST4.2×16 13
20A Machine Screw M4×12 1
21 Retaining Ring Ø42 1
22 Woolen Ring Ø30×Ø42×3 1
23 Oil Seal Ring Ø30xØ42x7 1
24 Hex Socket Bolt M6×25 4
25 Flat Washer Ø6×Ø10.5 4
26 Front housing 1
27 O Ring Ø54.5×Ø2.2 1
28 Hammer Staff Sheath 1
30 Impact Hammer 1
31 Hammer Ring 1
32 Vibration Reducing Cushion 1
33 Limit ring 1
34 Steel Ball SØ7.938 8
35 Check Ring 1
36 Spring 1
37 Ball Bearing 6907RS 1
38 Cylinder 1
39 Ratchet Spring Ring 1
40 Ratchet Spring 1
41 Ratchet Ring 1
42 Clutch Spring 1
43 Clutch 1
44 Steel Wire Block Ring Ø32 1
45 Big Cone-shaped Gear 1
46 Impact Piston 1
47 O Ring Ø21.1xØ3.5 2
48 Gas Press Piston 1
49 Piston Pin 1
50 O Ring Ø22×Ø2 1
51 Connecting Rod Asm. 1
51.1 Bushing 1
52 Oiliness Bearing Ø32×Ø37×12 1
53 Crank Housing 1
54 Machine Screw ST5.5×25 8
55 Oil Tank Cover 1
56 O Ring Ø25.12×Ø1.78 1
3DUW 'HVFULSWLRQ 4W\
57 Small Cone-shaped Gear 1
58 Ball Bearing 6904 VV 1
59 Final Gear 1
60 O Ring Ø5.5xØ1.05 1
61 Ball Bearing 608 RS 1
62 Crank Shaft 1
63 Ball Bearing 6004 1
64 Retaining Ring Ø20×1 1
65 Crankshaft Gear 1
66 Crankshaft Gear Washer 1
67 Needle Bearing HK101410 1
68 Seal Ring 1
69 Inner Cover 1
70 Ball Bearing NSK 6201 DDU 1
71 Oil Seal Ring Ø17×Ø32×7 1
72 Fan Guide 1
73 Screw ST4.8×58 2
75 Stator 1
76 Armature 1
77 Inductor 1
78 Ball Bearing NMB 608D 1
79 Bearing Ring 1
80 Housing 1
81 Carbon Brush 2
82 Carbon Brush Wire 2
83 Machine Screw ST3.5×16 4
84 Coil Spring 2
85 Fan Cover 1
86 Speed Control 1
87 Dual Indicator Lens 1
88 Flat Washer Ø5.5xØ14x1.6 2
89 Main Handle Seat 1
90 Shock Absorption Ferrule 2
91 Shock Absorption Spring 1
92 Shock Absorption Jacket 1
93 Main Handle 1
94 Trigger 1
95 Switch 1
96 Main Handle Cover 1
97 Cord Clip 1
98 Cord Armor 1
99 Cord 1
100 Ø2×14 Split Pin 1
101 Ø6×50 Shaft Pin 1
102 Bottom Shock Absorption Jacket 1
103 Hex Socket Bolt M6×20 2
104 Side Handle Asm. Steel Tie 1
105 Spring Column Pin Ø5×23 1
106 Ring Bolt 1
107 Side Handle Asm. Base 1
108 Wing Bolt 1
109 Depth Gauge 1
110 Nut M6 1
111 Side Handle Cover 1
112 Side Handle 1
115 Grease Tube 1
116 Seal Ø15.5xØ23.2x3.3 2
