Page 14 For technical questions, please call 1-888-866-5797. Item 57348
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Clamp Nut 1
2
Grinding Wheel
(sold separately)
0
3 Disc Flange 1
4 Wheel Guard, 4-1/2" 1
5 Screw, M5 x 16 1
6 Wheel Guard Lock Cover 1
7 O-Ring 1
8 Output Shaft 1
9 Screw, M4 x 14 4
10 Gear Box Cover 1
11 O-Ring 1
12 Dust Cap 1
13 Ball Bearing, 6201-RS 1
14 Corrugated Baffle Ring 1
15 Circlip 1
16 Output Gear 1
17 Needle Bearing, HK0810 1
18 Gear Box 1
19 Screw, ST4.2 x 22 6
20 Spindle Lock Button 1
21 Spring 1
22 O-Ring 1
23 Shaft Circlip 1
24 Side Handle 1
25 O-Ring 1
26 Nut, M6 1
Part Description Qty
27 Small Gear 1
28 Washer 1
29 Ball Bearing, 608-LUV 1
30 O-Ring 1
31 Middle Cover 1
32 Rotor 1
33 Dust Shield 1
34 Ball Bearing, 607-RS 1
35 Bearing Sleeve, 607 1
36 Fan Baffle 1
37 Post 2
38 Stator 1
39 Housing 1
42 Screw, ST3 x 8 4
43 Brush Holder 2
44 Brush Spring 2
45 Carbon Brush 2
46 Right Housing 1
47 Trigger Assembly 1
48 Screw, ST4.2 x 14 7
49 Left Housing 1
50 Cable Lead Plate 1
51 Power Cable 1
52 Cable Sleeve 1
53 Wrench 1
54 Wheel Guard, 5" (not shown) 1
55 Wheel Guard, 6" (not shown) 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 792363573481 when ordering parts.
