Page 13For technical questions, please call 1-888-866-5797.Item 63978
Part Description Qty
71 Washer 2
72 M16 Nylon Nut 1
73 Stationery Fence 1
74 M8 x 25 Screw 4
75 Left Sliding Fence 1
76 Right Sliding Fence 1
77 Fence Knob 2
78 M6 x 13 Screw 1
79 M6 x 24 Screw 1
80 Washer 1
81 Bevel Lock Handle 1
82 Bevel Scale 1
83 M5 x 16 Screw 2
84 Left Bevel Indicator 1
85 Right Bevel Indicator 1
86 M5 x 8 Screw 2
87 Washer 2
88 Head Lock-Down Pin Assembly 1
89 Head Lock-Down Pin 1
90 O-Ring 1
91 Wear Plate 2
92 Upper Guard 1
93 Linear Bearing 1
94 Shaft Assembly 1
95 6302 Bearing 1
96 Shaft 1
97 C-Ring 1
98 Pulley 1
99 M5 x 8 Screw 1
100 Spindle and Gear Set 1
101 Bearing Holder 1
102 Needle Bearing 1
103 Spindle 1
104 6003 Bearing 1
105 Cover 1
106 M4 x 6 Screw 2
107 Reduction Gear 1
108 Pad 1
109 M5 x 16 Screw 3
110 Spring 1
111 Spindle Lock Set 1
112 Spindle Lock 1
113 O-Ring 1
114 Dowel Lock Plate 1
115 M5 x 12 Screw 1
116 Wave Washer 1
117 Shaft Set 1
118 6202 Bearing 1
119 Shaft 1
120 Cover 1
Part Description Qty
121 Pulley 1
122 629 Bearing 1
123 M5 x 16 Screw 3
124 Blade Guide Holder Assembly 1
125 Blade Guide Holder 1
126 Blade Guide Light 1
127 Blade Guide Lens 1
128 Lock Cover 1
129 M5 x 16 Screw 2
130 Wire Cover 1
131 M4 x 15 Screw 2
132 Short Drive Belt 1
133 Dowel 1
134 Pulley 1
135 Washer 1
136 Washer 1
137 M6 x 16 Screw 1
138 Motor Set 1
139 Motor Front Cover 1
140 Armature Assembly 1
141 M5 x 40 Screw 1
142 Field Set 1
143 Motor Housing 1
144 M5 x 5 Screw 2
145 Brush Holder 2
146 Nylon Nut 2
147 Nut Holder 2
148 Field Set 1
149 Hex Shaft 2
150 Power Cord Clip 1
151 Bearing Cover 1
152 Baffle 1
153 Brush 2
154 Brush Cover 2
155 End Cap 1
156 M4 x 16 Screw 2
157 Dowel 2
158 Pulley 1
159 Washer 1
160 Washer 1
161 M6 x 16 Screw 1
162 C-Ring 1
163 M6 x 16 Screw 2
164 M6 x 16 Screw 2
165 Long Drive Belt 1
166 M8 x 16 Screw 1
167 Aluminum Belt Cover 1
168 M5 x 16 Screw 1
169 Belt Cover 1
170 M5 x 16 Screw 4
