Page 12 For technical questions, please call 1-888-866-5797. Item 63978
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Base 1
2 Foot 4
3 Miter Scale 1
4 M6 x 12 Screw 2
5 M6 x 13 Screw 2
6 Wrench Clamp 1
7 M5 x 10 Screw 1
8 Wrench 1
9 Table Pad 1
10 Table 1
11 Spring Sheet 1
12 M5 x 8 Screw 1
13 M5 x 10 Screw 2
14 M5 x 12 Screw 2
15 Rod 1
16 Retaining Sheet 1
17 M5 x 8 Screw 1
18 Miter Handle Assembly 1
19 Miter Handle 1
20 Detent Latch Button 1
21 Ø4.5 x 9 Rivet 2
22 Handle Support 1
23 Ø5 x 45 Pin 1
24 Nut 2
25 Miter Retaining Sheet 1
26 M5 x 13 Screw 2
27 Bolt 1
28 M10 x 69 Bevel Lock Bolt 1
29 M8 x 10 Screw 1
30 Kerf Board 2
31 M4 x 16 Screw 6
32 Miter Angle Indicator 1
33 M4 x 20 Screw 1
34 M8 x 30 Screw 1
35 Washer 2
Part Description Qty
36 M8 Nut 1
37 Bevel Detent Plate 1
38 Washer 2
39 M5 x 18 Screw 2
40 M5 x 25 Screw 2
41 Wave Washer 2
42 Pivot Assembly 1
43 Front Pivot 1
44 Left Sliding Bar 1
45 Right Sliding Bar 1
46 Pivot 1
47 Linear Bearing 1
48 Linear Bearing 1
49 Bevel Detent Plate 1
50 M5 x 10 Screw 2
51 Bevel Shaft 1
52 Bevel Clamp 1
53 Bevel Lock Handle 2
54 M4 x 12 Screw 2
55 Spring 1
56 Detent Shaft 1
57 Detent Shaft Driving Assembly 1
58 C-Ring 2
59 E-Ring 1
60 Bearing Cover 2
61 Washer 1
62 Felt Washer 1
63 M5 x 10 Set Screw 2
64 Rear Pivot 1
65 Pad 2
66 M8 x 8 Screw 2
67 M6 x 20 Screw 6
68 Rear Pivot Knob 1
69 Spring 1
70 Washer 1
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
