Page 9For technical questions, please call 1-888-866-5797.Item 59640
Hercules Corded and Cordless
1. Press Button, then pull Guide Bar out to expose Bolts.
2. Remove Bolts and Guide Bar.
Guide
Bar
Button
3. Slide Plate out of Guide bar, then replace Plate.
Plate
4. Install Table over Plate, positioning it as far out
as possible to create maximum work space.
5. Adjust Table so that Blade is
centered in Blade Channel.
6. Secure Table using Bolts (44), tighten securely.
Bolts
(44)
Table
Bauer Corded
1. Remove Bolts and Guide Bar.
2. Install Table where Guide Bar was, positioning it as
far out as possible to create maximum work space.
3. Adjust Table so that Blade is
centered in Blade Channel.
4. Secure Table using Bolts from
Guide Bar, tighten securely.
Table
Guide
Bar
Bolts
To Next Page
