36
A
B
1
(1) Throttle stop screw
(A) Decrease r/min (B) Increase r/min
CAUTION
!!
Do not attempt to compensate for faults in
other systems by adjusting idle speed. Visit
your Authorised Hero MotoCorp workshop
for scheduled carburetor adjustment.
NOTE
Always adjust the idle speed in i3s switch
“OFF” position.
î To adjust the free play, loosen the lock nut
(3). Turn the adjusting nut (4) to obtain the
specified free play.Tighten the lock nut and
check the adjustment.
(1) Free play 10-20 mm (2) Clutch lever
1
2
(3) Lock nut (4) Clutch cable adjusting nut
(A) Decrease free play (B) Increase free play
B
A
3
4
CLUTCH
Clutch adjustment may be required if the
acceleration to lag behind engine speed.
Normal clutch lever free play (1) is 10- 20
mm at the lever (2).
vehicle stalls when shifting into gear or tends
to creep or if the clutch slips, causing
î Adjust idle speed with the throttle stop
screw (1).
î Warm up the engine and park the vehicle
on the main stand.
IDLE SPEED: 1400 ± 100 R/MIN
achieve optimum performance and meet
emission standards.
However in case of specific requirement of
tuning due to engine stalling in idle speed,
please follow the instructions given here
under:
CARBURETOR (IDLE SPEED)
The carburetor is factory preset in order to
