HERO ACHIEVER 150 - REAR BRAKE ADJUSTMENT; Rear Brake Pedal Free Play

41
î Make free play (2) adjustments by turning
the adjusting nut (3).
î Apply the brake and check for free wheel
rotation when released.
î Make sure that cut-out on the adjusting nut
is seated on the brake arm pin (4) after
making final free play adjustment.
2
(1) Front brake lever (2) Free play 10-20 mm
B
A
(B) Increase free play (ACW)
(A) Decrease free play (CW)
(3) Adjusting nut (4) Brake arm pin
4
3
(3) Adjusting nut (4) Brake arm pin
ü
X
(A) Cut-out not seated (B) Cut-out seated
3
44
3
(1) Rear brake pedal (2) Free play 20-30 mm
2
CW- Clockwise ACW- Anticlockwise
1
1
NOTE
If proper adjustment cannot be obtained by
this method, visit your Authorised Hero
MotoCorp workshop.
î Park the vehicle on its main stand.
REAR BRAKE (Adjustment)
î free play Measure the brake pedal (1)
before brake starts to take hold. Free play
(2) should be 20-30 mm.
