HERO IGNITOR - Page 12

(1) Fuel gauge
(2) Horn switch
(3) Turn signal switch
(4) Clutch lever
(5) Rear view mirror
(6) Headlamp switch
(7) Pass lamp switch
(15) Neutral indicator
(16) Front brake lever
(17) Throttle grip
(18) Starter switch
(19) Ignition switch
(20) Fuel tank cap
(21) Leg guard
5
4
2
1
3
18
16
17
19
20
21
TOP VIEW
15
13 14
12
11
10
8
7
6
9
(12) Tachometer
(8) Dimmer switch
(9) Select / Reset buttons
(10) High beam indicator
(11) Turn signal indicator
(13) LCD panel
(14) Master cylinder
8
*Accessories and features shown may not be part of standard fitment.
