HERO IGNITOR - Page 13

(1) Starter motor
(2) Gear shift pedal
(3) Main stand
(5) Women pillion step
(6) Saree guard
(4) Side stand (10) Seat lock
(7) Rear turn signal lamp
(8) Tail / Stop lamp
(9) Rear grip
(11) Side cover left
(14) Front turn signal lamp
(13) Fuel valve
(15) Choke knob
(12) Battery compartment (inside)
(16) Front reflex reflector
9
LEFT SIDE VIEW
1
2
16
15
14
3
4
10
5
6
7
8
9
13 12 11
*Accessories and features shown may not be part of standard fitment.
