(2) Carburetor
(1) Pillion foot rest
(5) Kick starter arm
(6) Oil level dipstick
(4) Brake pedal
(3) Rider foot rest
(7) Caliper assembly
(9) Visor
(8) Headlamp
(10) Air suction valve (inside)
10
(12) Pillion seat
(11) Rider seat
(13) Rear reflex reflector
(14) Muffler
RIGHT SIDE VIEW
12
11
10
71
8
9
14
13
5
6
2 43
*Accessories and features shown may not be part of standard fitment.
