7 Tachometer Indicates engine r/min
1 Reset button Button when long pressed resets tripmeter to zero
2 Neutral indicator Light glows when vehicle is in neutral position
9 Fuel gauge Indicates approximate fuel quantity
3 Digital clock Indicates hour & minutes (refer page-13)
5 Speedometer Indicates riding speed
8 Turn signal indicator Flashes when turn signal switch is operated
4 Odometer / Tripmeter Shows accumulated mileage (refer page-14)
10 Select button Switches display between Odometer & Tripmeter
6 High beam indicator Light glows when headlamp is in Hi Beam
