45
The air cleaner is a viscous type paper filter
which has enhanced filtering efficiency.
The air cleaner should be replaced at
regular intervals (page 40). When riding in
dusty areas, more frequent replacement
may be necessary.
(1) Air cleaner cover screws
(2) Air cleaner rubber cover
(3) Air cleaner housing cover
2
1
3
Tighten a new spark-plug 1/2 turn after
the plug seats, with a spark plug box
wrench to compress the washer. If you
are reusing a plug, it should only take
1/8-1/4 turn after the plug seats.
3. Remove the element air cleaner (4).
2. Remove the air cleaner cover screws (1),
air cleaner rubber cover (2) and air
cleaner housing cover (3).
1. Remove the seat assembly (page 21-22).
