If they are tight the valves are open,
O
rotate the flywheel 360 anticlockwise
and re-align the 'T' mark with the index
mark.
(7) Feeler gauge
8
12
Install the parts in the reverse order of
disassembly.
If adjustment is required, adjust by
loosening the lock nut (6) and turning the
adjusting screw (5) until there is a slight
drag on the feeler gauge (7).
After tightening the lock nut (6), check the
clearance again.
