HERO IGNITOR - Lubrication

55
(3) Drive chain lock nut
(6) Rear edge of adjusting slot
(2) Sleeve nut
(4) Drive chain adjusting nut
(5) Index mark
65
4
3
59
OFF
2
NOTE
Visit Authorised Hero MotoCorp
workshop for inspection, cleaning,
lubrication and adjustment of drive chain at
every 2000 kms.
