(3) Gear shifting Maximum operating speed in each gear.
(4) Neutral indicator Light glows when vehicle is in neutral
(5) Fuel gauge Indicates approximate fuel quantity
(6) Side stand indicator Light glows when the vehicle is parked on the side stand
(7) High beam indicator Light glows when headlamp is in Hi Beam
(8) Turn signal indicator Flashes when turn signal switch is operated
Sl. No. Description Function
(2) Odometer Shows accumulated mileage
(1) Speedometer Indicates driving speed
3 5
8
4
headlamp.
6
7
2
1
PARTS FUNCTION
INSTRUMENTS AND INDICATORS
