47
Adjust the headlamp beam vertically
by rotating the screw. Rotate the screw
clockwise for downward adjustment
an d ant i clo c kw i se fo r upw a rd
adjustment of headlamp beam.
Park the motorcycle on level ground.
Headlamp adjustment is done by the
headlamp adjusting screw (1) located
below headlamp.
1
.
there
Check the rear shock absorber by pushing
hard downwards on rear carrier while the
motorcycle is not parked on stand. The
suspension action should be smooth and
there should be no oil leakage.
HEADLAMP ADJUSTMENT
Headlamp is factory pre-set. However in
case of adjustment required, please follow
the steps as given below :
headlamp
(1) Adjusting screw
