RES
At “RES”, fuel will flow from the reserve
fuel supply to the carburetor. Use the
reserve fuel only when the main supply is
exhausted. Refill the tank as soon as
possible after switching to “RES”. The
reserve fuel supply is 1.4 litres (usable).
3
2
1
15
At “OFF”, fuel cannot flow from the tank
to the carburetor. Turn the valve “OFF”
whenever the motorcycle is not in use.
The three way fuel valve is on the left side
of the carburetor.
OFF
FUEL VALVE
ON
At “ON”, fuel will flow from fuel tank to
the carburetor.
(1) “OFF” Position
(2) “ON” Position
(3) “RES” Position
