HERO SPLENDOR PRO - Throttle Operation; Throttle Free Play Adjustment; Valve Clearance

34
1
Slide the grommet (2), loosen the lock nut
(3) and turn the adjuster (4).
(4) Adjuster
(3) Lock nut
(2) Grommet
A
B
28
2
3
4
(1) Free play 2-6 mm
THROTTLE OPERATION
VALVE CLEARANCE
