USER’S MAUAL
HCP 4DK
POWER SUPPLY
Power supply voltage / fuse: 11÷15 VDC / 2 x 35 A
Idling current (power ON/OFF): 1.6 A / 0.05 mA
Consumption @ 2Ω, 14.4 VDC
(Max Musical Power):
40 A
Remote In: 7 ÷ 15 VDC - 1 mA
ART: Automatic Remote Turn-On/Off with Speaker-In
HCP 5D
POWER SUPPLY
Power supply voltage / fuse: 11÷15 VDC / 2 x 25 A
Idling current (power ON/OFF): 2 A / 0.04 mA
Consumption @ 2Ω, 14.4 VDC
(Max Musical Power):
30 A
Remote In: 7 ÷ 15 VDC - 1 mA
ART Automatic Remote Turn-On/Off with Speaker-In
AMPLIFIER STAGE
Features:
Distorsion - THD (100 Hz @ 4Ω): 0.03 %
Bandwidth: 10 ÷ 35K Hz
S/N Ratio (A weighted @ 1 V): 105 dB
Damping factor (100 Hz @ 4Ω): 200
Pre-In sensitivity: 0.2 ÷ 5 VRMS (15 kΩ)
Speaker-In sensitivity: 0.8 ÷ 20 VRMS (47Ω)
Load impedance (MIN):
@ 4 Ch:
2Ω
@ 3 Ch: 2Ω + 2Ω + 4Ω
@ 2 Ch: 4Ω
Output Power (RMS) @ 14.4 VDC, THD 1%
4 Ch: 120 W x 4 (4Ω)
4 Ch: 220 W x 4 (2Ω)
3 Ch: 120 W x 2 (4Ω) + 440 W x 1 (4Ω)
3 Ch: 220 W x 2 (2Ω) + 440 W x 1 (4Ω)
2 Ch: 440 W x 2 (4Ω)
Output Power (RMS) @ 14.4 VDC, THD 10%
4 Ch: 150 W x 4 (4 Ω)
4 Ch: 250 W x 4 (2 Ω)
3 Ch: 150 W x 2 (4 Ω) + 520 W x 1 (4 Ω)
3 Ch: 250 W x 2 (2 Ω) + 520 W x 1 (4 Ω)
2 Ch: 520 W x 2 (4 Ω)
AMPLIFIER STAGE
Features:
Distorsion - THD (100 Hz @ 4Ω): 0.02 %
Bandwidth FRONT/REAR: 10 ÷ 50k Hz
Bandwidth SUB: 10 ÷ 500 Hz
S/N Ratio (A weighted @ 1 V): 100 dB
Damping factor (100 Hz @ 4Ω)
FRONT/REAR:
100
Damping factor (100 Hz @ 4Ω) SUB: 250
Pre-In sensitivity: 0.2 ÷ 5 VRMS (15 kΩ)
Speaker-In sensitivity: 0.8 ÷ 20 VRMS (47Ω)
Load impedance (MIN)
@ 5 Ch
2Ω
@ 3 Ch: 4Ω + 4Ω + 2Ω
Output Power (RMS) @ 14.4 VDC, THD 1%
5 Ch: 55 W x 4 + 160 W x 1 (4Ω)
5 Ch: 90 W x 4 + 280 W x 1 (2Ω)
3 Ch: 180 W x 2 (4Ω) + 160 W x 1 (4Ω)
3 Ch: 180 W x 2 (4Ω) + 280 W x 1 (2Ω)
Output Power (RMS) @ 14.4 VDC, THD 10%
5 Ch: 65 W x 4 + 200 W x 1 (4Ω)
5 Ch: 105 W x 4 + 330 W x 1 (2Ω)
3 Ch: 210 W x 2 (4Ω) + 200 W x 1 (4Ω)
3 Ch: 210 W x 2 (4Ω) + 330 W x 1 (2Ω)
INPUTS / OUTPUTS / FILTERS
INPUTS: PRE IN / SPEAKER IN
Preout FULL range (FRONT): Yes
FRONT Ch. filters FULL: Yes
Hi-Pass: 50 ÷ 3.2k Hz @ 12 dB/Oct.
Lo-Pass: 50 ÷ 3.2k Hz @ 12 dB/Oct.
REAR Ch. filters FULL: Yes
Hi-Pass: 50 ÷ 3.2k Hz @ 12 dB/Oct.
Lo-Pass: 50 ÷ 3.2k Hz @ 12 dB/Oct.
FRONT Ch. MONO (on/off): Yes
REAR Ch. MONO (on/off): Yes
BOOST 50 Hz (select): (0 ÷ 12) dB
INPUTS / OUTPUTS / FILTERS
INPUTS: PRE IN / SPEAKER IN
FRONT Ch. filters FULL: Yes
Hi-Pass: 50 ÷ 5k Hz @ 12 dB/Oct.
REAR Ch. filters FULL: Yes
Hi-Pass: 50 ÷ 500 Hz @ 12 dB/Oct.
Band-Pass: 50 ÷ 500 Hz (Hi) @ 12 dB/Oct.
50 ÷ 5kHz (Lo) @ 12 dB/Oct.
SUB Ch. filter LO-PASS: 50 ÷ 500 Hz @ 24 dB/Oct.
SUBSONIC (on/off): 25 Hz @ 24 dB/Oct.
BOOST 50 Hz (adjust): (0 ÷ 12) dB
Remote Volume Control (adjust): (-50 ÷ 6) dB
CEA 2006-A Ratings
RMS Power
(4Ω,≤1 %THD+N, 14.4 V):
110 W x 4 Ch
S/N Ratio (ref. 1 W output):
85 dBA
CEA 2006-A Ratings
RMS Power
(4Ω,≤1 %THD+N, 14.4 V):
50 W x 4 Ch + 150 W + 1 Ch
S/N Ratio
(ref. 1 W output):
(50 W Ch) 83 dBA
(150 W Ch) 83 dBA
SIZE / WEIGHT
Max size (mm / in.): 315 x 190 x 50 / 12.40” x 7.48” x 1.97”
Weight (kg / lb.): 2,73 / 6.01
SIZE / WEIGHT
Max size (mm / in.): 345 x 190 x 50 / 13.58” x 7.48” x 1.97”
Weight (kg / lb.): 2,61 / 5.75
