Hertz HDP 4 - BATTERY; REMOTE CONNECTION AND HOW TO REPLACE THE FUSE; AUTO TURN-ON WITH HI-LEVEL INPUTS

7
BATTERY / REMOTE CONNECTION AND HOW TO REPLACE THE FUSE
AUTO-TURN ON WITH HI-LEVEL INPUTS
L L
R
A PRE - IN B PRE - INPRE - OUT
A HI - IN
B HI - IN
A B
HI-IN
AUTO
TURN-ON
ON OFF
B
INPUT
HDP4
R
+BATTERY
GND
REMOTE OUT
2 x 40 A
BLADE FUSES
ORIGINAL SOURCE
ORIGINAL
SOURCE
Apply a Fuse
close to positive
pole to protect
+BATTERY wire
Set the
“HI AUTO TURN-ON”
switch to the
“ON” position
Set the “HI AUTO TURN-ON”
switch to the “ON” position
HDP 4
Advanced Web Manual
