Hertz SPL Show - Installation Examples

User’s Manual
50
Adjustment
CONTROLS
Not
AVAILABLE
::
Set-up
CONTROLS
:
OUT +
OUT -
SUBWOOFER
min 1Ω
or
use RCA adapter
Provided
use RCA cable adapter
Not provided
L
R
R
R
L
L
REM IN
*
Select “HI [USS]” if you
connect speaker output
signals. Select “LO” if you
connect pre-out signals.
*USS: Universal Speaker
Simulater
LO
PRE OUTS
HI [USS]
SPEAKER OUT
*
CONTROLS SIDE
IN L
IN R
WHITE
RED
1 Ch OUT (2Ch IN L+R): One Subwoofer
CABLES SIDE
SP 1.900
SUBWOOFER
LO-PASS GAIN
7
INSTALLATION EXAMPLES
