Hertz SPL Show - Installation and Sizes

User’s Manual
42
2
INSTALLATION AND SIZES
1: Power supply cable
2: Speakers cable
Applied power Cable diameter
Connection length
*Current Draw I (A)
Cable Length (m)
3
CABLE SIZE CALCULATION TABLES:
1: Power supply cable / 2: Speakers cable.
C
A
E
B
D
A B C D E
SP 1.900
205 211,6 107 130 49
mm
8.07 8.33 4.212 5.118 1.929
in.
SP 4.500
185.7 192.7 107 130 49
mm
7.31 7.58 4.212 5.118 1.929
in.
SP 4.900
205 211,6 107 130 49
mm
8.07 8.33 4.212 5.118 1.929
in.
P
rotection
P
ow
er
