Heta Ambition 5 - Page 15

5
6
3
4
2
1
7
8
15
Pos. No. Name Qty.
1 0023-000103 Back stone top, left 1
2 0023-002740 Side stone, left 1
3 0023-002742 Baffle 1
4 0023-002741 Side stone, right 1
5 0023-000387 Back stone bottom, left 1
6 1013-004304 Stiffener 1
7 0023-004882 Back stone top, right 1
8 0023-004879 Back stone bottom, right 1
Ambition 5 Parts - Inside fire chamber
Ambition 8 Parts - Inside fire chamber
6
5
2
1
3
7
8
4
Pos. No. Name Qty.
1 0023-005003 Back stone top, left 1
2 0023-004994 Back stone bottom, left 1
3 0023-000105 Side stone, left 1
4 0023-000106 Baffle 1
5 0023-000108 Side stone, right 1
6 1013-004304 Stiffener 1
7 0023-005004 Back stone top, right 1
8 0023-004995 Back stone bottom, right 1
