Heta Ambition 5 - 2.7 Clearances for installation

D
C
A
B
150 150
300
D
B
B
21
2.7 Clearances for installation EN 13 240 Ambition
The dimensions are the
minimum dimensions,
unless otherwise stated.
Non-flammable substrate
Furnitures
Stove
Minimum
dimensions in
mm
Distance to flamable materials
A
rear the stove
with insulation /
without insulation
B
at the
sides
C
over
the
stove
D
to
furniture
Ambition 5
150/200 400
385
1100
Ambition 8 175/225 400 385 1100
Clearances for installation EN 13 240
- Non-flammable
substrate
By flammable floor material the
stove must be mounted on the log
store base and a non-flammable
substrate.
Combustible material
