Heta Scan-line 8 - Parts - Inside Fire Chamber

16
Parts - Scan-Line 8 -Inside fire chamber
Pos. No. Name Qty.
1 0023-0198 Upper baffle 900 Kg / M3 1
2 0023-0199 Baffle 1
3 0023-0200 Back stone top 1
4 0023-0201 Back stone bottom 1
5 0023-0202 Right side stone back 1
6 0023-0203 Left side stone back 1
7 0023-0204 Right side stone front 1
8 0023-0205 Left side stone front 1
9 0030-0023 Casted bottom 1
10 0030-0201 Grate 1
11 1519-0018 Log retainer 1
7
5
8
6
1
2
3
4
11
9
10
