Heta Scan-line 8 - Installation Clearances

23
Combustible material
2.6 Clearances for installation EN 13 240
320
1327
A
A
A-A
600
839
300
A
A
A
B
C
Not combustible
Furnitures
A
A
A
The dimensions are
the minimum dimen-
sions, unless other-
wise stated.
Ø 445
366
981
1029
222
875
125
97
Scan-Line 8
- With soapstone
- With soapstone top
and casted sides
1011
981
366
97
221
875
125
Ø 443
Scan-Line 8
- With casted sides
Stove
minimum
dimensions
in mm
Distance to flamable materials
A
rear the
stove
B
at the sides
C
to furnitures
Scan-Line 8 120 350 850
Scan-Line 8
Side windows
100 400 700
Clearances for installation
