18
Pos. No. Name Qty.
1 0023-006026 Vermiculite, front, right 1
2 0023-006028 Vermiculite, rear, bottom 1
3 0023-006029 Vermiculite, narrow sid, right 1
4 0023-006032 Vermiculite, rear, top 1
5 0023-006050 Vermiculite, under Side windows 2
6 0023-006110 Baffle, two-part, right 1
7 0023-006467 Vermiculite, front, left 1
8 0023-012056 Vermiculite, smal side, left 1
9 0023-012057 Baffle, two-part, left 1
10 0030-0201 Grate, Ø195 mm 1
11 0030-006009 Casted bottom 1
12 1013-006262 Baffle rail 1
13 0023-3017 Gasket L = 850 1
14 4018-0053 Ash container 1
8
10
3
9
12
6 4
2
7
1
5
14
11
13
5
Scan-Line 900 Side windows Parts - Inside fire chamber
