MICROTSCM (07/09) Page 1
REV 2.4
Specifications
Measurement Range
± 10.0 SCU or ICu
Accuracy
±1 % of Full Scale
Repeatability
1%
Linearity
±1%
Resolution
0.01 SCU or ICu
Response Time
1 second
Analyzer Display
Backlit Graphical LCD with trending
Alarms
Two Programmable, One Sensor, 120-240VAC 2A Form C Relay
Analog Output
Powered 4-20 mA, 1000 Ω drive
Communications Port
Optional RS-232 or RS-485
Flow Rate
6.0 – 9.5.0 L/min. (1.5 -2.5 gpm)
Flow Alarm
Optional Float Switch
Operating Temperature
0°C – 50°C (32°F – 122°F)
Storage Temperature
-20°C – 60°C (-4°F – 140°F)
Wetted Materials
HDPE, PTFE, Stainless Steel, Neoprene, ABS
Standard Cable Length
7.62m (25 feet)
Max. Sensor to Analyzer
76.25 m (250 feet) Consult factory for lengths over 50 feet
Power Source
120 or 240 VAC, 50/ 60 Hz, 40VA
SCM Sensor Case
Designed to meet IP 66 /NEMA 4X
Analyzer Regulatory
Compliance And
Certifications
CE Approved, ETL listed to UL 3111-1 &
ETL Certified to CSA 22.2 No. 1010-1-92
Shipping Weight
Instrument: 9.5 kg (21 lbs.)
Calibration kit: 5.5 kg (12 lbs.)
Shipping Dimensions
Instrument: 61 cm X 46 cm X 35cm (24“ X 18 “ X 14”)
Calibration kit: 41cm X 41 cm X 38 cm (16” X 16” X 15”)
Warranty
1 Year from date of shipment
