HF-LPX30 Series Low Power WiFi Module User Manual
Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com) - 8 -
1.1.2 Device Paremeters
Table1. HF-LPT230 Module Technical Specifications
Class Item Parameters
Wireless
Parameters
Certification FCC/CE/SRRC/RoHS
Wireless standard 802.11 b/g/n
Frequency range 2412-2472MHz
Transmit Power
802.11b: +16 +/-2dBm (@11Mbps)
802.11g: +14 +/-2dBm (@54Mbps)
802.11n: +13 +/-2dBm (@HT20, MCS7)
Receiver Sensitivity
802.11b: -87 dBm (@11Mbps ,CCK)
802.11g: -73 dBm (@54Mbps, OFDM)
802.11n: -71 dBm (@HT20, MCS7)
Antenna Option
HF-LPT230:
Tested antenna type: PCB antenna
Antenna inferface port: IPEX port
Hardware
Parameters
Data Interface
UART
GPIO,SPI
Operating Voltage 2.9~4.2V
Operating Current
Peak (Continuous TX): 260mA
Average(STA, No data): 18mA(DTIM=1),
14mA(DTIM=3)
Average(STA, Continuous TX): 24mA
Average(AP): 80mA
Shutdown(reset pull low):60uA
Operating Temp.
-40℃- 85℃
0℃- 105℃(High Temperate Version)
Storage Temp.
-40℃- 125℃
Density
<85%
Dimensions and Size
HF-LPT230:
22mm x 13.5mm x 3mm
Software
Parameters
Network Type STA/AP/AP+STA
Security Mechanisms WEP/WPA-PSK/WPA2-PSK
Encryption WEP64/WEP128/TKIP/AES
Update Firmware Local Wireless, Remote OTA
Customization Support SDK for application develop
Network Protocol IPv4, TCP/UDP/HTTP/TLS(SDK)
User Configuration
AT+instruction set. Android/ iOS
SmartLink APP tools
1.2. Hardware Introduction
HF-LPT230 series Wi-Fi module appearance is as following.
