5.3.4. Write Serial number command
This command writes the sensor serial number.
Command word: 0x0010
Command value: 2 bytes serial number length + 8 bytes serial number
Return value: 2-byte ACK status (0 succeeded, 1 failed)
Send data: (for example：SN is 12345678)
ACK(Success):
Frame head
Intra-frame
data length
Command
word
ACK
Frame end
FD FC FB FA
0400
1001
0000
04030201
5.3.5. Read serial number command
This command reads the sensor serial number.
Command word：0x0011
Command value
：
None
Return value：2-byte ACK status (0 succeeded, 1 failed) + 2-byte serial number length + 8-
byte serial number
Send data:
Sensor ACK：（Success, serial number: 12345678）
Frame head
Intra-frame
data length
Command
word
Serial
number
length
Serial number
Frame end
FD FC FB FA
0C00
10 00
0800
31 32 33 34 35 36 37 38
04 03 02 01
Frame head
Intra-
frame data
length
Command word
Frame end
FDFCFBFA
0200
1100
04030201
Frame
head
Intra-frame
data length
Command word
ACK
Serial
number
length
Serial number
Frame
end
FDFCFBFA
0E00
1101
0000
0800
3132333435363738
04030201
