2. System description
HLK-LD2410S is a battery-powered ultra-low-power millimeter-wave sensor based on Hi-
Link's millimeter-wave sensor chip. The sensor uses FMCW FM continuous wave, radar signal
processing and built-in intelligent low-power body sensing algorithm to detect the human body
target in the set space and update the detection results in real time. With this millimeter-wave sensor
reference solution, users can quickly develop their own precise, low-power body sensing products.
The hardware LD2410S is mainly composed of a fully integrated intelligent millimeter wave
sensor SoC, a 24 GHz antenna and a main control MCU. The software part is combined with the
low-power human presence sensing algorithm firmware and visual configuration tool released by
Hi-Link to realize the human body sensing function that can flexibly configure sensing distance,
trigger and hold thresholds, unreported time and data refresh rate.
Table 2-1 lists the specifications of HLK-LD2410S:
Table 2-1 HLK-LD2410S specification
Parameter
Min
Typ
Max
Unit
Remark
HLK-LD2410S
Hardware
specifications
Supported frequency
band
24
-
24.25
GHz
Comply with
FCC, CE, no
committee
Certification
standard
Maximum scanning
bandwidth supported
-
0 . 25
-
GHz
-
Maximum equivalent
omnidirectional
radiated power
-
10
-
dBm
-
Power supply
3 . 0
3 . 3
3.6
V
-
Size
-
20 × 20
-
mm
2
-
Ambient temperature
-40
-
85
°C
-
HLK-
LD2410SSystem
performance
Range detection
range
(Wall hanging, 1.5
meters high)
-
10
-
m
Moving human
object detection
-
4
-
m
Stationary human
target detection
Average working
current
0 . 04
0 . 12
0 . 6
mA
Office scene
Data refresh cycle
1
40
60
s
Configurable
