Page #17 background image
Instruction manual
HLK-LD2450
Shenzhen Hi-Link Electronic Co.,Ltd
17
8 Performance and electrical parameters
Operating
frequency band
24GHz~ 24.25GHz
Comply with FCC, CE, Commission-
free certification standards
Power supply
requirements
DC 5V, power supply capacity >200mA
Average operating
current
120 mA
Modulation method
FMCW
Interface
One UART
Target application
Detection and tracking of up to three
targets
Detection distance
6m
Detection angle
±60 °
Data refresh rate
10Hz
Sweep bandwidth
250MHz
Compliant with FCC, CE, Commission-
free certification standards
Ambient temperature
-40 ~ 85℃
Dimension
15mm x 44 mm
Table 4 Table of performance and electrical parameters
