Hi-Link HLK-SW16 User Manual

深圳市海凌科电子有限公司 Shenzhen Hi-Link Electronic Co.,Ltd
Http://www.hlktech.com Tel:0755-23152658 Fax:0755-83575189
Shenzhen Hi-Link Electronic Co.,Ltd 3
Remote Web management
Configuration file import and export
Network management
WEB software upgrade
Serial to Ethernet
Maximum transmission
rate
500000bps
TCP connection Max connection number>20
UDP connection Max connection number>20
Serial baud rate
1200~500000bps
Other Parameters
Status indicator Status indicator
Operating temperature：-20-70℃
Operating humidity：10%-90%RH（noncondensing）
Storage temperature：-40-80℃
Environmental standard
Storage humidity：5%-90%RH（noncondensing）
Additional properties
Frequency bandwidth optional：20MHz、40MHz，Automatic
1.2
Electrical Characteristics

1.Input Power: 5V
2.Input Current: 2A
3.Relay Maximum input voltage: 220v
4.Relay Maximum Input Current: 10A
5.Input and output: 16 outputs
6.Default IP: 192.168.16.254
7.The default port number: 8080
8.Networking Series: No restrictions
