function
Binding Post
P1-P8
16 way 220v，10A relay
STA STA
Indicates the connection status of the client and
the server:
ON: client and server has been connected
Off: client and server is not connected
Flashing: The client and server is going on data
communication
WIFI
WIFI indicator, when wifi working, wifi light
starts blinking, if it has data transmission ,
accelerate flashes
LED
LED3-18 LED3-18
Indicates the Work status of relay
ON: relay works
OFF: relay break
RST RST MCU reset
Button
Exit/Default Exit/Default
Short Press (0.5-5 seconds): module go into
the AT command mode
Long press (more than 6 seconds): restore
factory default settings
1.5
Typical Application
Handheld device
Remote control
Consumer Electronics
IOT application
Industial control
Medical device
LED control
Sensor network application
