HID iCLASS SE Express R10 User Manual

November 2018
iCLASS SE® Express R10 Installation Guide
PLT-03681, Rev. A.23
3. Secure the reader to the backplate
4. Power and test the reader
1. Align the top of the reader with the
top of the backplate.
2. Hook the top of the reader on the
top of the backplate.
3. Align the bottom of reader with the
bottom of the backplate.
4. Secure the reader to the backplate
using one of the supplied screws:
Security/non-tamper screw:
0.138-32 x 0.375" screw (supplied)
Non-security/standard screw:
0.138-32 x 0.375" screw (supplied)
Turn on the power. The reader should
beep and the light bar should flash.
Test the reader with a card. The buzzer should
beep and the LED should flash.
1
2
3
4
