1.1 MR62e reader interface
The MR62e OSDP reader interface provides a network connected interface to control two physical barriers using OSDP
readers and provides a solution for the OEM integrator for interfacing to OSDP readers and door hardware. The on-board
Ethernet with PoE/PoE+ support enables easy installation. The MR61e supports up to four OSDP readers configured as
paired or alternate readers.
Caution: For UL, the Power Sourcing Equipment (PSE) such as a PoE/PoE+ enabled network switch
and/or PoE/PoE+ power injectors must be UL Listed under UL294B.
One serial 2-wire RS-485 communication port is available that can accommodate up to four OSDP readers.
Four Form-C relay outputs can be used for door strike control or alarm signaling. The relay contacts are rated at 2 A @ 30
V DC, resistive and are in a dry contact configuration.
Six inputs are provided that can be used for monitoring the door contacts, exit push buttons, and alarm contacts. Input
circuits can be configured as unsupervised or supervised.
The MR62e requires PoE, PoE+ or local 12 V DC for power.
The MR62e may be mounted in a 3-gang switch box; a mounting plate is supplied with the unit or be mounted in an
enclosure; the supplied mounting plate has mounting holes that match the MR50 mounting footprint.
PLT-05249, A.1 4 August 2022
