1. Terms A & B are from the RS-485 standard.
2.2 Jumpers
Jumper Set at Description
J1 N/A Ethernet connection with PoE/POE+ support.
J2 N/A Factory use only.
J3 N/A Tamper switch (normally open contact). See 4.1 Additional mounting information
J4 N/A RS-485 Termination, install only if the MR62e is at the end of the communication bus.
J5 PoE MR62e powered from the Ethernet connection.
VIN MR62e powered from an external 12 V DC power source
connected to TB4-3 (VIN), TB4-4 (GND).
J6 – J13 N/A Factory use only.
2.3 DIP switches
The four switches on S1 DIP switch are used to configure the operating mode of the MR62e. DIP switches are read on
power-up except where noted.
1 2 3 4 Definitions
OFF OFF OFF OFF Normal operating mode.
ON X OFF OFF After initialization, enable default User Name (admin) and Password (password). The switch is
read on the fly, no need to reboot. See 2.12 IT security for additional information.
OFF ON OFF OFF Use factory default communication parameters.
ON ON OFF OFF Use OEM default communication parameters. Contact system manufacture for details. See 2.5
Bulk erase.
ON ON OFF OFF Bulk Erase prompt mode at power up. See 2.5 Bulk erase.
All other switch settings are unassigned and reserved for future use. X = don’t care.
2.4 Factory default communication parameters
Network: static IP address 192.168.0.251
Subnet mask 255.255.0.0
Default gateway 192.168.0.1
PLT-05249, A.1 8 August 2022
