HID ProxPro II 5455 - Product Components and Specifications; Included Parts List; Reader Specifications; Multi-Technology Card Guide

5455-910 Rev. D.1
p a r t s
•1reader
•2#6-32x1"self 
tapping
TypeTor23screws 
•1installationmanual
Recommended
•9wiresplices
•1grommet
•1cable,5-9 
conductor 22AWG
shielded
•LinearDCpower 
supply
Specifications
•Voltagerange:
5.0-16.0 VDC
•Current:
max. average -
40mA
•500'max.cable 
distance to host
c o m p o n e n t e s
•1lector
•2módulosde 
autoderivación del
N.º681x2,5cm(32x1
pulg)tipo"T"o23
•1manualde 
instalació
Recomendable
•9empalmadores
•1arandela
•1cable,conductor
 (5-9)blindado 
calibre 22 AWG
•Fuentede 
almentación lineal
CD
Especificaciones
•Intervalodevoltaje
5-16 VCC
•Corriente:
promedio máx - 40
mA
•Longitudmáx.del 
cable al sistema
central: 150 m.
p i è c e s
•1lecteur
•2vis  
autotaraudeuses
 nº6;81x2,5cm,
detypeTou23
•1manuel 
d'installation
Recommandations
•9épissuresdecâble
•1passe-fil
•1câbleblindé
conducteur5-9fils
dediamètre0,35 
mm
2
•Alimentationlinéaire
cc
Spécifications
•Plagedetension:
 5,0-16,0Vcc
•Courant:
moyen max. : 40
mA
•Distancede 
 câblage 
max. avec le
système
central : 150m
p e ç a s
•1leitor
•2cabosTipoTou23
 nº6(81x2,5cm)
auto-adesivos
•1manualde 
instalação
Recomendado
•9fiosconectores
•1anelisolante
•1cabo,condutor5- 
922AWG,blindado
•RedeelétricaCA 
linear
Especificações
•Amplitudede 
variação de
voltagem-
 5,0VCA-16,0VCA
•Mediadecorrente 
máx. 40 mA
•150mdedistância 
máxima do cabo
ao host
t e i l e
•1reader
•2#6-32x1Zoll
(81x2,5cm)
gewindefurchende
Schrauben Typ T
•1installierung 
handbuch
Empfohlen:
•9Kabelspleißer
•1Gummidichtung
•1Kabel,5-9Leiter22
AWG,abgeschirmt
•LineareGleichstrom-
versorgung
Spezifikationen
•5,0VGleichspannung
-16,0V
Gleichspannung
•40mAmaximale
durchschnittliche
spannung
•150mmaximale
Kabelentfernung zum
Host
40
c o m p o n e n t i
•1lettore
•2#6-32x1"self 
tapping
TypeTor23screws •
Manuale di
installazione
Raccomandato
•Connettore9poli
•1pressacavo
•1cavo,5-9 
condutorre 22AWG
schermato
•alimentatorelineare
DC
Specifiche
•Rangedilavoro:
5.0-16.0 VDC
•Corrente:
Max 40 mA
•Max500mtdi 
distanza dall’host
Pb
Pb-free
