Hides HV-320 - Board View

Easy HD Expressway!
WWW.HIDES.COM.TW 3
Board View
RF-out
UART
Configuration
Port
HDMI-in
CVBS-in
Video
Line-in
Audio
12V/5V
DC-in
SD card
7-SEG LED
CH+/-
button
Reset button
(bottom side)
Power
LED
IR
UART Debug &
Data mux
SPI flash kit
Connector
SPI Boot
strapping
