High Tech Pet MS-5 - Installing and Replacing the MS-5 Battery; Steps for Battery Installation and Replacement

___________________________________________________________________________________________
High Tech Pet Products, Inc. www.hightechpet.com 3
INSTALLING/ REPLACING THE MS-5 BATTERY
1. Unscrew the bottom cover.
4. Remove and replace B3V1A battery
2. Pry bottom off at the
location shown here, using
a small at-blade screw-
driver or metal nail le.
3. Remove bottom, note battery orientation
5. With new battery installed, close case.
Squeeze until bottom ush with top, by
squeezing top and bottom together
6. Insert and tighten screw.
