Multi-spectrum Binocular User Manual
14
Chapter 3 Image Settings
You can set palettes, brightness, scenes, FFC (flat field correction), and DPC (defective
pixel correction) to display the better image effect.
3.1 Adjust Device
Figure 3-1 Adjust Device
Adjust Infrared Light
Slightly rotate to adjust the beam angle of the infrared light. The broader the beam angle
is, the more spread-out but less intense the light will be.
Adjust Focus
Slightly rotate the focus ring to adjust the focus of the objective lens.
Note
DO NOT touch the lens directly with your finger, or place any sharp objects near them.
Adjust Interpupillary Distance
Adjust the interpupillary distance by moving the eyepieces farther or closer to each other.
Adjust Diopter
Make sure the eyepiece covers your eye and aim at the target. Adjust the diopter
adjustment ring until the OSD text or image is clear.
