Hikmicro M10 User Manual

Handheld Thermography Camera User Manual
1
Chapter 1 Overview
1.1 Device Description
The handheld thermography camera is a device with both optical images and thermal images. It
can do thermography, video recording, snapshot capturing, alarm, and it can connect to Wi-Fi,
hotspot and Bluetooth. The built-in high-sensitivity IR detector and high-performance sensor
detects the variation of temperature and measure the real-time temperature. The temperature
measurement range is -20 °C to 550 °C (-4 °F to 1022 °F) with the accuracy of ± 2 °C (± 3.6 °F) or ±
2% when the ambient temperature is 15°C to 35 °C (59 °F to 95 °F) and the object temperature is
above 0 °C (32 °F).
The picture-in-picture technique of the camera and the fusion of optical view and thermal view,
enhances the details of the images display. It supports multiple palettes and alarm types. When
the detected temperature in the scene does not match with the alarm rules, the device alarms by
color of the palette mode automatically. It helps to find the risky part and lower your property loss,
but it can not be used for human body temperature test.
The device is easy to use, and adopts ergonomic design. It is widely applied to substations,
electricity prevention detection of companies, and reconnaissance survey of construction field.
1.2 Main Function
Thermography
Device detects the real-time temperature, and display it on the screen.
Storage
Device is equipped with memory module to store videos, snapshots, and important data.
Fusion
Device can display fusion of thermal view and optical view.
Palette and Alarm
Device supports multiple palettes, and you can set the palette mode according to the alarm
function.
Client Software Connection
● Mobile Phone: Use HIKMICRO Viewer to see live image, capture, and recording, etc. on your
phone.
● PC: Use HIKMICRO Analyzer to see live image, capture, recording, and receive alarm message,
etc., on your PC.

Hikmicro M10 Specifications

General

USB port	Yes
USB connector type	USB Type-C
Micro HDMI ports quantity	1
Sensor type	-
Fixed focal length	25 mm
Sensor resolution (thermal module)	640 x 480 pixels
Input voltage	100 - 240 V
Charging source	USB
Cables included	HDMI, USB
Number of batteries included	2 pc(s)
Battery capacity	- mAh
Battery life (max)	4 h
Battery recharge time	2.5 h
Safety	IEC 61010-1
Display type	LCD
Certification	Australian RCM
Product color	Black
Tripod thread	1/4-20 \
Display diagonal	5 \
Display resolution	1280 x 720 pixels
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
International Protection (IP) code	IP54
Accuracy	2 °C
Laser type	Class II
Laser wave power	1 mW
Laser wavelength	635 nm
Total megapixels	8 MP
Camera pixel size	17 µm
Measurement modes	Center spot, Cold spot, Hot spot, Off
Standard palettes	Black Hot, Fusion, Rain, Rainbow, Red Hot, White Hot
Maximum resolution	3264 x 2448 pixels
Infrared spectral band	8 - 14 µm
Vertical field of view	18.7 °
Horizontal field of view	24.8 °
IFOV (spatial resolution)	0.68 mRad
Thermal sensitivity (NETD)	30 mK
Sensor type (thermal module)	Vanadium Oxide Uncooled Focal Plane Arrays
Temperature measurement range	-20 - 650 °C
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Languages support	Multi
Management software	HIKMICRO Analyzer, HIKMICRO Viewer App, UVC Alarm Clien
Number of languages	21
Video memory capacity	64 h
Compatible memory cards	SD
Image formats supported	JPEG
Video formats supported	MP4
Maximum memory card size	128 GB
Memory capacity (images)	60000
Sustainability certificates	RoHS

Weight and Dimensions

Depth	118.3 mm
Width	284.7 mm
Height	127.1 mm
Weight	653 g
