HIKVISION DS-2CD2012-I Technical Manual

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
3
DS-2CD2012-I
Key Features
 Up to 1.3 megapixel (1280 × 960) resolution
 Standard video compression with high compression ratio
 Progressive scan CMOS, capture motion video without incised margin
 Support dual stream, and the sub-stream for mobile surveillance
 High-performance and long service life Infrared LED, Approx. 20 to 30 meters IR range
 IR cut filter with auto switch
 PoE (Power over Ethernet)
 Ingress Protection level: IP66
 Auto-iris, electronic shutter for different surveillance environments
 Other functions: heartbeat, alarm, reset button, mirror, etc.
Specification
Model
Parameter
DS-2CD2012-I
1.3 Megapixel CMOS ICR Infrared Network Mini Bullet Camera
Camera
Image Sensor
1/3" Progressive Scan CMOS
Min. Illumination
0.01 Lux @ (F1.2, AGC ON) ,0 Lux with IR
Shutter Speed
1/25 s to 1/100,000 s
Lens
6mm@ F2.0 (4mm, 12mm optional)
Lens Mount
M12
Day &Night
IR cut filter with auto switch
Digital Noise
Reduction
3D DNR
Compression Standard

HIKVISION DS-2CD2012-I Specifications

General

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Form factor	Bullet
Product color	White
International Protection (IP) code	IP66
Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 960, 640 x 480 (VGA), 704 x 576
Camera shutter speed	1/25(1/30) - 1/100000 s
Minimum illumination	0.01 lx
Field of view (FOV) angle	73.1 °
Sensor type	CMOS
Optical sensor size	1/3 \
Lens diameter	4 mm
Focus adjustment	2.0
Password protection type	User
LED type	IR
Night vision distance	30 m
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	5 W
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Width	139.28 mm
Height	76.9 mm
Weight	500 g
Diameter	60.4 mm
