HIKVISION DS-2CD2043G2-I User Manual

17
Reset and Restore Camera
Press Reset button for about 10s when the camera is
powering on or rebooting to restore the default settings,
including the user name, password, IP address, port No.,
etc.
For the position of the reset button, refer to the gure in the
interface introduction page.

HIKVISION DS-2CD2043G2-I Specifications

General

Type	IP security camera
Certification	FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: 6, 2016); KC (KN 32: 2015, KN 35: 2015) UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(1):2010+A1:2013+A2:2015)
Number of languages	33
Placement supported	Outdoor
Connectivity technology	Wired
Infrared (IR) cut-off filter	Yes
Number of cameras	1
Sustainability certificates	REACH, RoHS
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP67
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
DC output current	0.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6 W
Power consumption (Power over Ethernet (PoE))	7 W
Wi-Fi	No
Number of users	32 user(s)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Behavior analysis	Intrusion detection, Line crossing detection
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels	4 MP
Maximum resolution	2688 x 1520 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	40 m
Fixed focal length	2.8 mm
Maximum aperture number	1.6
Pan range	0 - 360 °
Tilt angle range	0 - 90 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \

Weight and Dimensions

Length	161.7 mm
Weight	490 g
Diameter	70 mm
Package depth	121 mm
Package width	216 mm
Package height	118 mm
Package weight	724 g
