Network Turret Camera·Quick Start Guide
Steps:
Disassemble the camera. 1.
1). Rotate the trim ring anticlockwise to take it off from the
camera.
2). Rotate the mounting base anticlockwise to take it off from the
camera.
3). Separate the camera and the enclosure.
Trim Ring
Mounting Base
Enclosure
Camera
①
②
③
Disassemble the Camera Figure 2-15
Install the memory card. 2.
1). Find the Micro SD/RST cover on the side of the camera.
Micro SD/RST Cover Figure 2-16
To Next Page
