HIKVISION DS-2CD2332-I Quick Start Guide

Network Turret Camera·Quick Start Guide
36
36
Install the camera and the enclosure to the mounting base, 8.
adjust the surveillance angle, and fix the trim ring.
Refer to corresponding steps in ceiling mounting of each
camera type.
Pendant Mounting Figure 2-36
2.3 Network Cable Waterproof Accessory
Installation
Purpose:
If the camera is installed outdoor, you can adapt the waterproof
accessory for the network cable after the camera is secured on the
installation surface.

HIKVISION DS-2CD2332-I Specifications

General

Type	IP security camera
PTZ control	-
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP66
Total megapixels	3 MP
Maximum resolution	2048 x 1536 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1280 x 960, 1536 x 2048, 1280 x 720 (HD 720)
Pan range	0 - 360 °
Tilt angle range	0 - 75 °
Angle of rotation	360 °
Camera shutter type	Electronic
Camera shutter speed	1/100000 s
Minimum illumination	0 lx
Field of view (FOV) angle	75.8 °
Sensor type	CMOS
Optical sensor size	1/3 \
Optical zoom	- x
Fixed focal length	- mm
LED type	IR
Night vision distance	30 m
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1X, Qos
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Power source type	PoE
Power consumption (max)	5.5 W
Power consumption (typical)	7.5 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Width	127 mm
Height	97.5 mm
Weight	670 g
