Network Turret Camera·Quick Start Guide
Install the Mounting Base Figure 2-19
Connect the corresponding power/network cable. Refer to the 5.
section 2.3 for the waterproof accessory installation if the
camera is installed in the outdoor.
Install the camera along with the enclosure to the mounting 6.
base by anticlockwise rotating the camera.
Install the Camera Figure 2-20
Rotate the enclosure to adjust the pan angle; rotate the camera 7.
to adjust the tilt angle.
