Network Turret Camera·Quick Start Guide
Drill Template
Mounting Base
Fix Mounting Base Figure 2-26
Connect the corresponding power/network cable. Refer to the 6.
section 2.3 for the waterproof accessory installation if the
camera is installed in the outdoor.
Install the camera along with the enclosure to the mounting 7.
base.
Install the Camera Figure 2-27
Adjust the surveillance angle of the camera. Secure the fixing 8.
screw after adjustment.
To Next Page
